NAMUR Mounted, Pilot Operation Spool Type Solenoid Valve EEx me II T5. Aluminum Encapsulated Coil Enclosure, CNOMO Interface. Robust Coil Unit With Integral Terminal Box.

Scan QR code to join this website!QR_NAMUR-EEx_m_Aluninum_Solenoid_Valve

Features

Namur EEx m Aluminum Solenoid Valve
    Ex m, Exm, EExm, EEx me II T5, NAMUR Mounted, Pilot Operation, Spool Type, Aluminum Encapsulated Coil Enclosure, CNOMO, Solenoid Valve FEATURES :
  • Ex m, Exm, EExm, EEx me II T5, NAMUR Mounted, Pilot Operation, Spool Type, Aluminum Encapsulated Coil Enclosure, CNOMO, Solenoid Valve : Integral terminal box with coil housing.
  • Ex m, Exm, EExm, EEx me II T5, NAMUR Mounted, Pilot Operation, Spool Type, Aluminum Encapsulated Coil Enclosure, CNOMO, Solenoid Valve : Stainless steel 316 spool for all model.
  • Ex m, Exm, EExm, EEx me II T5, NAMUR Mounted, Pilot Operation, Spool Type, Aluminum Encapsulated Coil Enclosure, CNOMO, Solenoid Valve : Interchangeable CNOMO interface for various coil options available.
  • Ex m, Exm, EExm, EEx me II T5, NAMUR Mounted, Pilot Operation, Spool Type, Aluminum Encapsulated Coil Enclosure, CNOMO, Solenoid Valve : Single coil spring return function or double coil stay put function.
    • .
  • Ex m, Exm, EExm, EEx me II T5, NAMUR Mounted, Pilot Operation, Spool Type, Aluminum Encapsulated Coil Enclosure, CNOMO, Solenoid Valve : Inner epoxy molded coil.
  • Ex m, Exm, EExm, EEx me II T5, NAMUR Mounted, Pilot Operation, Spool Type, Aluminum Encapsulated Coil Enclosure, CNOMO, Solenoid Valve : Wide range of voltages available.
  • Ex m, Exm, EExm, EEx me II T5, NAMUR Mounted, Pilot Operation, Spool Type, Aluminum Encapsulated Coil Enclosure, CNOMO, Solenoid Valve : Low power consumption.
  • Ex m, Exm, EExm, EEx me II T5, NAMUR Mounted, Pilot Operation, Spool Type, Aluminum Encapsulated Coil Enclosure, CNOMO, Solenoid Valve : NAMUR adaptor to convert 5/2 to 3/2 function.
    Ex m, Exm, EExm, EEx me II T5, NAMUR Mounted, Pilot Operation, Spool Type, Aluminum Encapsulated Coil Enclosure, CNOMO, Solenoid Valve INTRODUCTION :
  • N series solenoid valve is designed for direct mounting onto 1/4 turn pneumatically operated valve actuators meeting “NAMUR”standard fixing dimensions.Suitable for Zones 1 and 2, manufactured in accordance with the requirements of the European harmonized standards EN50014. IIC T5.
    Ex m, Exm, EExm, EEx me II T5, NAMUR Mounted, Pilot Operation, Spool Type, Aluminum Encapsulated Coil Enclosure, CNOMO, Solenoid Valve VALVE :
  • Ex m, Exm, EExm, EEx me II T5, NAMUR Mounted, Pilot Operation, Spool Type, Aluminum Encapsulated Coil Enclosure, CNOMO, Solenoid Valve Body and End Caps : Aluminum and Stainless Steel 316
  • Ex m, Exm, EExm, EEx me II T5, NAMUR Mounted, Pilot Operation, Spool Type, Aluminum Encapsulated Coil Enclosure, CNOMO, Solenoid Valve Spool : Stainless Steel 316
  • Ex m, Exm, EExm, EEx me II T5, NAMUR Mounted, Pilot Operation, Spool Type, Aluminum Encapsulated Coil Enclosure, CNOMO, Solenoid Valve Seals : H-NBR
  • Ex m, Exm, EExm, EEx me II T5, NAMUR Mounted, Pilot Operation, Spool Type, Aluminum Encapsulated Coil Enclosure, CNOMO, Solenoid Valve Spring : Stainless Steel
  • Ex m, Exm, EExm, EEx me II T5, NAMUR Mounted, Pilot Operation, Spool Type, Aluminum Encapsulated Coil Enclosure, CNOMO, Solenoid Valve Port Connection Size : 1/4” - 3/8” NPT
  • Ex m, Exm, EExm, EEx me II T5, NAMUR Mounted, Pilot Operation, Spool Type, Aluminum Encapsulated Coil Enclosure, CNOMO, Solenoid Valve Working Pressure Internal Pilot Version : 2 to 8 bar
  • Ex m, Exm, EExm, EEx me II T5, NAMUR Mounted, Pilot Operation, Spool Type, Aluminum Encapsulated Coil Enclosure, CNOMO, Solenoid Valve Cv Factor : 2.0
  • Ex m, Exm, EExm, EEx me II T5, NAMUR Mounted, Pilot Operation, Spool Type, Aluminum Encapsulated Coil Enclosure, CNOMO, Solenoid Valve Maximum Ambient Temperature : +65°C
  • Ex m, Exm, EExm, EEx me II T5, NAMUR Mounted, Pilot Operation, Spool Type, Aluminum Encapsulated Coil Enclosure, CNOMO, Solenoid Valve Minimum Working Temperature : -10°C
    Ex m, Exm, EExm, EEx me II T5, NAMUR Mounted, Pilot Operation, Spool Type, Aluminum Encapsulated Coil Enclosure, CNOMO, Solenoid Valve COIL :
  • Ex m, Exm, EExm, EEx me II T5, NAMUR Mounted, Pilot Operation, Spool Type, Aluminum Encapsulated Coil Enclosure, CNOMO, Solenoid Valve Coil Case : Zinc Alloy Epoxy Powerder Coated
  • Ex m, Exm, EExm, EEx me II T5, NAMUR Mounted, Pilot Operation, Spool Type, Aluminum Encapsulated Coil Enclosure, CNOMO, Solenoid Valve Armature : Magnetic Solenoid Quality Stainless Steel
  • Ex m, Exm, EExm, EEx me II T5, NAMUR Mounted, Pilot Operation, Spool Type, Aluminum Encapsulated Coil Enclosure, CNOMO, Solenoid Valve Springs : Stainless Steel
  • Ex m, Exm, EExm, EEx me II T5, NAMUR Mounted, Pilot Operation, Spool Type, Aluminum Encapsulated Coil Enclosure, CNOMO, Solenoid Valve Seals and Seat : Viton
  • Ex m, Exm, EExm, EEx me II T5, NAMUR Mounted, Pilot Operation, Spool Type, Aluminum Encapsulated Coil Enclosure, CNOMO, Solenoid Valve Coil Former : 30% Glass Filled PBT
  • Ex m, Exm, EExm, EEx me II T5, NAMUR Mounted, Pilot Operation, Spool Type, Aluminum Encapsulated Coil Enclosure, CNOMO, Solenoid Valve Magnetic : Class H Coated Copper
    Ex m, Exm, EExm, EEx me II T5, NAMUR Mounted, Pilot Operation, Spool Type, Aluminum Encapsulated Coil Enclosure, CNOMO, Solenoid Valve DC Solenoid Coil :
  • Ex m, Exm, EExm, EEx me II T5, NAMUR Mounted, Pilot Operation, Spool Type, Aluminum Encapsulated Coil Enclosure, CNOMO, Solenoid Valve Voltage Standard : 24
  • Ex m, Exm, EExm, EEx me II T5, NAMUR Mounted, Pilot Operation, Spool Type, Aluminum Encapsulated Coil Enclosure, CNOMO, Solenoid Valve Voltage Tolerance : ±10%
  • Ex m, Exm, EExm, EEx me II T5, NAMUR Mounted, Pilot Operation, Spool Type, Aluminum Encapsulated Coil Enclosure, CNOMO, Solenoid Valve Ambient Temperature : -10 to +65°C
  • Ex m, Exm, EExm, EEx me II T5, NAMUR Mounted, Pilot Operation, Spool Type, Aluminum Encapsulated Coil Enclosure, CNOMO, Solenoid Valve Duty Cycle : 100%
  • Ex m, Exm, EExm, EEx me II T5, NAMUR Mounted, Pilot Operation, Spool Type, Aluminum Encapsulated Coil Enclosure, CNOMO, Solenoid Valve Degree of Protection : IP66
  • Ex m, Exm, EExm, EEx me II T5, NAMUR Mounted, Pilot Operation, Spool Type, Aluminum Encapsulated Coil Enclosure, CNOMO, Solenoid Valve Connection : Flying Leads
  • Ex m, Exm, EExm, EEx me II T5, NAMUR Mounted, Pilot Operation, Spool Type, Aluminum Encapsulated Coil Enclosure, CNOMO, Solenoid Valve Power Consumption : 0.4 Watts with Barrier
  • Ex m, Exm, EExm, EEx me II T5, NAMUR Mounted, Pilot Operation, Spool Type, Aluminum Encapsulated Coil Enclosure, CNOMO, Solenoid Valve Pressure Range : 0 - 8 bar
    Ex m, Exm, EExm, EEx me II T5, NAMUR Mounted, Pilot Operation, Spool Type, Aluminum Encapsulated Coil Enclosure, CNOMO, Solenoid Valve AC Solenoid :
  • Ex m, Exm, EExm, EEx me II T5, NAMUR Mounted, Pilot Operation, Spool Type, Aluminum Encapsulated Coil Enclosure, CNOMO, Solenoid Valve Voltage Standard : 110, 220, 50/60 Hz
  • Ex m, Exm, EExm, EEx me II T5, NAMUR Mounted, Pilot Operation, Spool Type, Aluminum Encapsulated Coil Enclosure, CNOMO, Solenoid Valve Voltage Tolerance : ±10%
  • Ex m, Exm, EExm, EEx me II T5, NAMUR Mounted, Pilot Operation, Spool Type, Aluminum Encapsulated Coil Enclosure, CNOMO, Solenoid Valve Ambient Temperature : -10 to +65°C
  • Ex m, Exm, EExm, EEx me II T5, NAMUR Mounted, Pilot Operation, Spool Type, Aluminum Encapsulated Coil Enclosure, CNOMO, Solenoid Valve Duty Cycle : 100%
  • Ex m, Exm, EExm, EEx me II T5, NAMUR Mounted, Pilot Operation, Spool Type, Aluminum Encapsulated Coil Enclosure, CNOMO, Solenoid Valve Degree of Protection : IP66
  • Ex m, Exm, EExm, EEx me II T5, NAMUR Mounted, Pilot Operation, Spool Type, Aluminum Encapsulated Coil Enclosure, CNOMO, Solenoid Valve Connection : Flying Leads
  • Ex m, Exm, EExm, EEx me II T5, NAMUR Mounted, Pilot Operation, Spool Type, Aluminum Encapsulated Coil Enclosure, CNOMO, Solenoid Valve Power Consumption : 0.4 Watts with Barrier
  • Ex m, Exm, EExm, EEx me II T5, NAMUR Mounted, Pilot Operation, Spool Type, Aluminum Encapsulated Coil Enclosure, CNOMO, Solenoid Valve Pressure Range : 0 - 8 bar
    Ex m, Exm, EExm, EEx me II T5, NAMUR Mounted, Pilot Operation, Spool Type, Aluminum Encapsulated Coil Enclosure, CNOMO, Solenoid Valve ENCAPSULATION SAFETY :
  • Type ‘m’ (Encapsulation) is a type of protection in whitch the parts which could ignite an explosive atmosphere by either sparking or heaying are encloses in a compound in such a way that the explosive atmosphere cannot be ignited.
  • The R.G.S. ‘m’ coil is housed in a metal enclosure which is potted with epoxy resin to form a hermetically sealed unit. A thermal fuse is embedded in the resin to prevent the coil overheating in the event of a fault.
    Ex m, Exm, EExm, EEx me II T5, NAMUR Mounted, Pilot Operation, Spool Type, Aluminum Encapsulated Coil Enclosure, CNOMO, Solenoid Valve CABLE GLANDS AND CABLE :
  • The coil must be protected for a propective short circuit current of 4000A by providing a fuse in the supply with a breaking capacity of 4000A. The recommended rating for each fuse is 250mA for all EEx’m’ coil voltages.
